Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification

China Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification supplier
Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification supplier Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification supplier Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification supplier

Large Image :  Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification

Product Details:

Place of Origin: Jiangsu,China
Brand Name: Sussman
Certification: CE ISO 9001
Model Number: SM-TB

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard Packing with steel wire fixed and film coated
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P, D/A
Supply Ability: 10 set per month
Contact Now
Detailed Product Description
Forming Speed: 12-15m/min Material Thickness: 1.5-2.0mm Galvanized Steel And Black Steel
Forming Stations: 18 Stations Dirve System: Chain Drive 1.5 Inches 20A Double Chain With Longer Shafts
Power Supply: 380V, 50Hz, 3Phase Main Motor Power: 11 KW
Cutting: Hydraulic Cutting Cr12mov Hydraulic Station Power: 5KW

Q235 Steel Shelving Racking Forming Machine 12-15 m/min CE Certification



Roll Forming Machine Technical Parameter


Main Specifications

Suitable Plate Material: thickness 1.5-2.0mm, Galvanized steel or blank steel
Working Speed: 12-15 meters / min
Forming Steps: 18 stations
Material of Roller: Gcr15, Quench HRC58-62 Plated Chrome
Material of Shaft: 45# Advanced Steel (Diameter: 76mm), thermal refining
Driven system: Chain drive
Main Power with reducer: 11KW WH Chinese Famous
Cutting: Hydraulic Cutting Cr12mov
Material of Cutting Knife: Cr12Mov, Quench HRC58-62
Hydraulic Station Power: 5KW Wuxi Wanshen Famous Chinese Brand
The whole machine is controlled by industry computer-PLC.

PLC--Panasonic, Japan English and Chinese Language
Touch Screen--Panasonic Japan

Encoder--Omron, Japan

Electric parts--Schneider


Machine’s Components


Equipment name

Quantity

Servo feeding device 400mm

1 set

3T hydraulic de-coilers

1 set

Leveling device 400mm

1 unit

Press machineJH21-80

1 unit

Main roll forming machine 18 stations

1 set

Cutting holder

1 set

Hydraulic station

1 set

Control system ( including control box)

1 set

Out tables

2 units

Hydraulic Cutting die

1 set

Punching die set

1 set

Spare parts

1 package



Working Flow of Roll Forming Machine

Decoiling---Guiding and Leveling---Punching---Roll Forming----Cutting----Product Collecting


Profile drawing
 Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification




Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification


Packaging & Delivery


Packaging Details:
Standard package with film, plastic and steel wire. (or customized)
1. need about ten 40ft containers for loading one set machine completely, 2. the whole Wiped Anti Rust Oil, PLC controller covered by foam film, 3. Spare parts and some small parts packed in plastic tooling box, 4. All Components Fixed by steel wire with Container.
Delivery Detail:Shipped in 45 working days after payment


 Q235 Steel Shelving Rack Roll Forming Machine 18 Stations CE CertificationQ235 Steel Shelving Rack Roll Forming Machine 18 Stations CE Certification


Advantage for Roll Forming Machine

1. Reasonable Price

2. High Quality

3. 12 Months Warranty

4. More Than 10 Years Experience

5. Durable

6. Afrer-sales service
