Stainless Steel 0.05-0.25mm Steel Coil Embossing Machine Production Line Metal Embossing Machine
|
Embossing roller size
|
Φ350-450mm; width 1000-1600mm
|
|
Embossing roller pattern
|
Convex hull, corn grain, Pearl pattern, ball and other patterns. (Patterns can be customized.)
|
|
Aluminum plate size
|
Thickness≤ 0.8mm
|
|
|
Max. width 1500mm
|
|
Embossing roller material
|
Alloy steel solid forging
|
|
Embossing mode
|
Upper and lower concave-convex rollers Opposing pressure
|
|
Pressure adjustment
|
Turbo-worm reducer pressurize
|
|
Transmission mode
|
Gear transmission
|
|
Voltage and Power
|
380V/50HZ 3P; speed 0-10m/min
|
|
Technological Process
|
Decoiler → embossing (knurling) forming → Finished products.
|
1.Uncoiling Machine
1.Outline data: About 2000×900×1350mm
2.coiled material mode:Φ200×1200mm air shaft
3.support the weigh: ≤1000kg
4.Side with brake systems: Magnetic powder brake
2.Embossing Machine
|
Product Name |
Metal embossing machine |
|
Material Specification |
stainless steel |
|
Thickness |
0.05-0.25 mm |
|
Max. Coil Width |
1250mm |
|
Working Speed |
0-8m/min |
|
Motor power |
4kw |
|
Machine Dimension |
About 2400mm*900mm*1300mm |
|
Total Weight |
About 1500kg |
|
Voltage |
380v/3phase/50HZ or as customer's requirement |
|
Roller Material |
45# steel |
|
Width of Roller |
1200mm |
|
Embossing Pattern |
As per the samples or the customer’s requirement |
3.Recoiling Machine
1.Outline data: about 2600×900×1350mm
2.coiled material mode:Φ200×1200mm air swelling shaft
3.support the weigh: ≤1000kg
4.Motor power: 220V 60Hz 3Phase 100 Nm torque motor,Speed: 0-18m/min
5.Gas rising axis side can be fine-tuned before and after
4. Flower Pattern
5.Applications
Wall cladding, facades, roofs and canopies, tunnels, column covers or renovations, wall cladding, ceilings, bathrooms, kitchens and balconies.
6. Embossing Machine Photo
