0.7 - 1.5 Mm Galvanized Steel 1.5B Type Roof Deck Roll Former Machine High speed 20m/min

Product Description:

The Floor Deck Roll Forming Machine operate with high speed and precision, making it an ideal choice for continuous production.

The machine is made with a robust construction and features a hardness rating of HRC58-62, roller material of 45# steel, 28 roller stations, and a thickness range of 0.7-1.5mm.

The Floor Deck Roll Forming Machine is designed for maximum efficiency and accuracy, making it the perfect choice for manufacturing floor deck.

It is easy to operate and maintain, making it a great choice for industrial production. It is made from high-quality steel, making it strong and durable. The machine has a long service life and is highly cost-effective.

Features:

Technical Parameters:

Customization profile:

We made many floor decking machines for the North American countries, such as the America,Canada, Mexico, Colombia, Especially for the America, we already sent many floor decking machines there, we have customer from New York,Florida, Texas, California as so on.
The floor decking machine America use are almost same and standard1.5B type is one they normally used, 2 inches and 3 inches composite deck and the material thickness they used are Gauges 16 18 20 22 as so on.

Most of the metal floor decking panel are 36” effective width and 48” input material width.

Photo:

Packaging and Shipping of Floor Deck Roll Forming Machine

Floor Deck Roll Forming Machine is packaged with waterproof plastic film and then loaded into wooden case to protect it from moisture, dust and damage during shipping. The wooden case is then sealed with screws and labeled with product name and shipping information.

The Floor Deck Roll Forming Machine is usually shipped by sea or air freight. If the customer has special requirements, we can also arrange other modes of transportation, such as railway, road and express.
