Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations
Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations

Large Image :  Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations

Product Details:
Place of Origin: China
Brand Name: Sussman
Certification: CE; ISO9001
Model Number: CZ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 23900-35900 Per Set
Packaging Details: Naked packing
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 2 sets per month

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations

Description
Plate Material: Galvanized Steel Thickness: 1.0-3.0mm
Forming Speed: 12-15 Meters / Min Roller Stations: 20 Stations
Roller Material: Gcr15, Quench HRC58-62 Plated Chrome Driven System: Chain Drive
Main Motor Power: 15kw Control System: PLC Computer Control With Inverter
Tolerance: ±1.5mm Dimension: 9600mm*1500mm*1500mm
High Light:

c purlin roll forming machine

,

z purlin roll forming machine



Chain Drive Z Purlin Roll Forming Machine With 20 Roller Stations



Technical Parameter

  • Material: aluzinc/galvanized steel/colored steel coil
  • Material thickness: 1.0-3.0mm
  • Main motor power: 15kw
  • Pump power: 7.5kw
  • Shaft diameter: 80mm
  • Forming steps: 5+14steps
  • Roller material: bearing steel
  • Main frame: 400H steel
  • Medium plate thickness: 20mm
  • Control systerm: PLC computer control with inverter
  • Power supply: 460V, 3 Phase,60Hz or as requirement
  • 0veral size: 9600mm*1500mm*1500mm



Working Flow

Decoiler—→level device—→main forming machine—→straightening—→hydraulic Punching —→hydraulic cutting—→ run out table

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 0

Machine List



S.N Equipment name Quantity
1 3T manual uncoiler 1 set
2 Levelling device 1 unit
3 Punching station (including punching mould) 1 unit
4 Main roll forming machine 1 set
5 Main drive 1 unit
6 Cutting unit 1 set
7 Hydraulic station 1 set
8

Control system

( including control cabinet)

1 set
9 Out put rack 1 set
10 Cutting mould 3 sets










Pictures of the product

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 1Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 2Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 3Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 4











Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 5

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 6



Workshop:



Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 7

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 8Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 9Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 10



Exihibiton:



Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 11

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 12



Shipping:



Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 13Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 14

Chain Drive Z Purlin Making Machine , Purlin Rolling Machine With 20 Roller Stations 15



Our services:



Sussman hereby solemnly promises: We implement the “three guarantees” service policy for any equipment sold by Sussman, provide free of charge installation guidelines, commissioning and maintenance of the equipment, training of the Buyer’s relevant Operators; and provide technical requirements for the installation and operation of the equipment, technical layout diagrams and other related information, provide a lifetime supply of maintenance and spare parts

The detailed measures are as follows:

1.Guidelines for installation and commissioning of equipment:

Based on the actual situation, to assist and guide the Buyer and Buyer’s technical personnel in the overall installation location, the installation of equipment, and provide Buyer with answers to their questions and related issues;



2.Provide training for operation and maintenance personnel:

Based on the Buyer’s request, Sussman will provide free of charge training of the operation and maintenance personnel;

a) The User (Buyer) can send their operation and maintenance personnel to our factory for learning and training;

b) When Sussman is doing the installation and test running of the equipment for the Buyer, the Buyer can send their personnel to participate.



3.If failure occurs in any of the machines during the “three guarantees” period(one year), then, upon the Buyer’s request, Sussman will eliminate the failure;



4. Sussman will inform all its Buyers about any upgrades and significant product improvements. Sussman will provide equipment modifications based on their costs. Sussman will provide Buyers with high-quality after-sales services in a careful and responsible attitude, provide very strong guarantee for the Buyer’s normal production.

We provide quick and satisfactory customer service, and promise to respond within 24 hours after receiving your complaints by phone or email
