Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
  • Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
  • Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
  • Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
  • Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
  • Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height
Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height

Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height

Place of Origin China
Brand Name SUSSMAN
Certification SGS,CE ,ISO9001
Model Number SS-FD
Product Details
Type:
Deck Floor Roll Forming Machine
Material Thickness:
0.8-1mm
Forming Stations:
13 Stations
Roller Material:
Gcr15, Quench HRC58-62 Plated Chrome
Dirve System:
Chain Drive
Speed:
0-10 Meters/min
High Light:

Chain Drive Deck Roll Former

,

Gcr15 Floor Deck Forming Machine

,

Self Lock Floor Deck Machine 1mm

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiable
Packaging Details
Standard Packing with film coated and steel wire fixed
Delivery Time
60-90 working days
Payment Terms
L/C, T/T,
Supply Ability
10 sets per month
Product Description

Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height





Technical Parameter



  Items Specifications
Material of coil Material Thickness 0.6-1.0mm
  Profile width

Width150mm



  Profile height As per drawing
  Un Coiler 3 tons manual
Forming system Rolling Speed About 10m/min
  Roller Stations About 13 stations
  Roller Material

Gcr15 coated with chrome


  Maim Motor Power 7.5 kw
  Motor cutting Power 4kw

Cutting

system

 Material Of Cutting CR12mov with quench treatment
  Hardness HRC58-62
  Tolerance +-1.5mm
Electrical control system Electric Source

415V, 50HZ,3 phase

Also can satisfy Customer’s requirey
  Control System PLC (Panasonic) as list in the note
  Weight About 3 tons
  Way Of Drive 1 inch chain



Machine List

Machine list 3 ton passive de-coiler 1 set
  Main roll forming machine 1 set
  PLC Control box 1 unit
  Hydraulic station 1 unit
  Out table 2 units
  Seaming machine 1 unit




Working Flow of Machine



Uncoiling—Feeding&Leveling--Roll forming—Cutting—Products collecting








 Standard Profile Drawing of product



Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 1

Application



Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 2







Loading Picture



Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 3Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 4

Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 5Self Lock Floor Deck Roll Forming Machine 1mm Thickness 100mm Height 6
