Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min
  • Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min
  • Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min
  • Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min

Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min

Place of Origin China
Brand Name Sussman
Certification SGS,CE ,ISO9001
Model Number SS-FD
Product Details
Name:
Galvanized Steel Floor Deck Roll Forming Machine
Material:
Galvanized Steel
Material Thickness:
0.8-1.2mm
Forming Stations:
28 Stations
Roller Material:
Gcr15, Quench HRC58-62 Plated Chrome
Dirve System:
Chain Drive
Power Supply:
380V, 50Hz, 3Phase
Forming Speed:
Up To10-12m/min
Machine Weight:
About 8 Tons
Machine Size:
8mx0.88mx1m
High Light:

corrugated roll forming machine

,

metal forming equipment

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiable
Packaging Details
Standard Packing with film coated and steel wire fixed
Delivery Time
60-90 working days
Payment Terms
L/C, T/T,
Supply Ability
10 sets per month
Product Description

Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working Speed 8-12m/min





Floor Deck Making Machine Technical Parameter



Item NO



Description



1

Steel Thickness

0.75-1.2mm

2

Product Line Speed

up to 12

3

Roller station

28 stations

4

Roller Material

45# steel

5

Shaft diameter

90

6

Main Motor Power

18.5kw

7

Hydraulic cutting Power

7.5KW

8

Hydraulic pressure

12KW

9

Power Supply

380V, 50HZ,3 phase

10

Tolerance

1.5mm

11

Material of cutting

Cr12

12

Control system Panasonic

 PLC with touch screen



Machine List



No

Name

quantity

1

5 ton passive de-coiler

1 set

2

Main roll forming machine

1 set

3

PLC system

1 unit

4

Hydraulic station

1 unit

5

Out tables

2 units





Working Flow of Machine



Uncoiling—Feeding&Leveling--Roll forming—Cutting—Products collecting








Standard Profile Drawing of product



Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min 1

Machine Photo



Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min 2



Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min 3



Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min 4



Fully Automatic Galvanized Steel Roll Forming Machine For Roof Deck Working 8-12m/min 5
