Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine
  • Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine
  • Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine
  • Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine

Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine

Place of Origin China
Brand Name Sussman
Certification CE; ISO9001
Model Number CZ
Product Details
Production Capacity:
10~20meter/min
Type:
CZ Purlin Roll Forming Machine
Main Motor Power:
22kw Roll Forming Machine
Control System:
PLC Control Panel Roll Forming Machine
Roller Material:
GCr15 Roll Forming Machine
Material Thickness:
1.0-3.0mm
Roller Station:
18 Stations
High Light:

15m/min CZ Purlin Roll Forming Machine

,

3.0mm CZ Purlin Roll Forming Machine

,

22kw CZ Purlin Roll Forming Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
USD 25,000 -35,000 Per Set
Packaging Details
Naked packing
Delivery Time
30 days
Payment Terms
T/T
Supply Ability
2 sets per month
Product Description

Building Material Machinery C Z Purlin Roll Forming Machine Working Speed 10-15m/min



Purlin Roll Forming Machine can form hot/cold rolled steel strip and get various specification purlins: C Purlin, Z Purlin, M Purlin, U Purlin.The forming speed can reach to 30m/min .It is fully automatic cold forming line for steel structure industry.
Inline flexible punching system integrated.
C and Z Profile changeovers automatically.
Dimension changeovers automatically.
Material thickness Guage 1.5mm~3.5mm
Straightening unit adapted to easily rectify the distortion and straightness from the bias of material.

Interchangeable C/Z purlin Roll Forming Machine manufactures both Cee & Zee shaped section channels with shapes and sizes quick changed by PLC control.
For a steel structural building project, people always use Cee and Zed steel purlins (different web sizes and different flange sizes).

Production Characteristic and Use of CZU Purlin Roll Forming Machine
One machine can produce differenct C/Z Purlins throught automatically stepless adjustment, when producing different profiles, no need to change forming rollers. In the process, machine adopt automactic control model, it can make auto pumch, cut, forming based on inputting length of purlin, holes distance, quantity, etc.
One side fixed, the other side adjustable
Manual or motorized servo positioning of moveable head
Designed for efficient production of various panel widths
It is quick and easy to operate the machine, high production efficiency, forming speed up to 20m/min.
This machine can produce C , Z, U three profiles, through the exchange side of the roller up and down position to achieve C , Z, U purlin conversion, just need less than one minute to achieve.







Working Flow

Decoiler—→level device—→main forming machine—→straightening—→hydraulic Punching —→hydraulic cutting—→ run out table

Building Material 15m/Min 3.0mm CZ Purlin Roll Forming Machine 0
