Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations

Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations
Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations
Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations

Large Image :  Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations

Product Details:
Place of Origin: China
Brand Name: SUSSMAN
Certification: CE, SGS, ISO9001
Model Number: SS-VY
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Standard package with film, plastic and steel wire. (or customized)
Delivery Time: 60-90 working days after payment
Payment Terms: L/C, T/T
Supply Ability: 10 sets per month

Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations

Description
Material: Galvanized Steel Sheet Voltage: 220v, 60hz, 3phase
Shaft Diameter: Φ60mm ,material Is 45# Forge Steel Roller Material: 45# Steel With Quenching 60mm Shaft
Cutting Tolerance: 6m+-1.0mm Power Supply: 380V, 50Hz, 3Phase
Main Motor Power: 7.5 KW
High Light:

Vineyard Roll Forming Equipment

,

G550 Roll Forming Equipment

,

G550 roll forming machine

16 Stations Galvanized Steel Sheet G550 Vineyard Post Roll Forming Machine



Vineyard is widely used for grape stake at Chile, Peru, Spain, France, it is light, easy to move and not easy be broken compare to the normal wooden stake.



 Technical Parameter



1.1 Rolling speed 2-3m/min
1.2 Rolling thickness 1.2-2mm
1.3 Raw material Galvanized steel sheet G550
1.6 dimension 6500×600×1200(mm)
1.7 Effective width 50mm
1.8 Roller stations

About 16 stations



1.9 Roller material Gcr15, coated with chrome, Quenching
1.10 Shaft diameter Φ60mm ,material is 45# forge steel
1.11 Transmission By Chain
1.12 Material of chain 45# forged steel with frequency quenching, 12A
1.13 Main Motor 7.5kw
1.14 Material of cutting Cr12Mov with quench HRC58-62°
1.15 Cutting Tolerance 6m+-1.0mm
1.16 Voltage 220v, 60hz, 3phase





 Main Components



S.N

    Equipment Name

Quantity

1

3T hydraulic De-coiler

1 set

2

Leveling device 200mm

1 set

3

Servo feeding device 200mm

1 unit

4

Press machineJH21-63

1 unit

5

Main roll forming machine

1 set

6

Cutting holder

1 set

7

Hydraulic station

1 set

8

Control system ( including control box)

1 set

9

Out tables

2 units

10

Spare parts

1 package

16

Cutting dies

1 set

17

Punching die set

1 set









Working Flow of Roll Forming Machine



Decoiler----feedingwithguide---Punching----Rollforming----Cutting----Products collecting






Profile of product







Loading pictures




Galvanized Steel Sheet G550 Vineyard Roll Forming Equipment 16 Stations 5







After-sale Serive

   - The seller take responsibility to installation and commissioning of the equipment and free training. After machine arrive the destination, by the request of the buyer , the seller will provide 1 technical engineer to guide installation and training , and the buyer should give the technical person with full cooperated.
   - Installation period: about 5 days after the complete preparation by the buyer such as the foundation and all necessary accessories.
   - Training time: 5 days.
   - Before departure of the engineers from seller, the buyer should pay for installation and commissioning fee 100$/day to the point account of the seller. The two-way ticket,visa, food, hotel , the translator and insurance are all should provide by buyer with full responsibility.
   -The seller supply technical data (including forming mould drawing, electrical elements drawing and equipment drawing etc.)
