| Place of Origin | China |
| Brand Name | SUSSMAN |
| Certification | CE, SGS, ISO9001 |
| Model Number | SS-FP |
0.45mm-0.7mm Thickness Fence Panel Roll Forming Machine With PPGI Galvanized Steel
The fence system includes fence post, fence rail track and fence panel. It needs 3 sets of roll forming machines.
Technical Data
Rolling Speed: About 8-12m/min
Steel sheet Thickness: 0.45 mm to 0.7mm PPGI,Galvanized Steel
Roller Stations: about 18 stations
Roller Material : 45# forge steel, coated with chrome
Shaft Material and DIA: ￠76mm, material is 45# forge steel, Chrome with quenching
Main Motor Power:7.5kw
Hydraulic Pressure: 12Mpa
Power supplier: 380V, 50HZ,3 phase or customized as customer’s requirement
Way Of Drive:by chain
Color Of The Machine :blue or customized
The size of the forming machine: About 8500*1500*1500mm
Machine weight: about 8 tons
Control system: PLC control panel with touching screen
Machine List:
| 5 ton manual de-coiler | 1 set |
| Feeding with guide | 1 set |
| Main roll forming machine | 1 set |
| Hydraulic cutting device | 1 set |
| PLC Control box | 1 set |
| Hydraulic station | 1 set |
| 4m out table | 1 set |
| Safety cover | 1 set |
Profile Drawing:
Application:
Spare Parts
| Name | Number | |
| Tools | Feeler gauge | 1 |
| Size spanner | 1 | |
| Inner hexagon spanner | 1 | |
| Clamp | 1 | |
| Standard spanner | 1 | |
| Shifting spanner | 1 | |
| Slotted screwdriver | 1 | |
| Other accessories | Chain | 2 pieces |
| Bearing (Haerbin) | 4 pieces |
After-sale Serive
- The seller take responsibility to installation and commissioning of the equipment and free training. After machine arrive the destination, by the request of the buyer , the seller will provide 1 technical engineer to guide installation and training , and the buyer should give the technical person with full cooperated.
- Installation period: about 5 days after the complete preparation by the buyer such as the foundation and all necessary accessories.
- Training time: 5 days.
- Before departure of the engineers from seller, the buyer should pay for installation and commissioning fee 100$/day to the point account of the seller. The two-way ticket,visa, food, hotel , the translator and insurance are all should provide by buyer with full responsibility.
-The seller supply technical data (including forming mould drawing, electrical elements drawing and equipment drawing etc.)
