Product Details:
|
| Slitting Speed: | 0-40m/min | Coil Width: | 1600 |
|---|---|---|---|
| Coil I.D: | 480-520 | Coil Weight: | 12 Ton |
| Slitting Blade Shaft: | 200 | Material Of Blade: | 6CrW2Si |
| High Light: | Steel Slitting Machine,Metal Slitting Machine |
||
1.Hydraulic and electric control at the same time
2.easy to operate
3.the whole line is adjustable
Specifications
| 1 | Control model | Frequency conversion control | |
| 2 | Application | Hot or cold rolled steel, galvanized steel | |
| 3 | Thickness | mm | 1-4 |
| 4 | Width (Max) | mm | 1250 |
| 5 | Coil I.D | mm | 508-610 |
| 6 | Coil O.D | mm | ≤1000 |
| 7 | Weight | T | 5T |
| 8 | Blades | mm | Φ120×Φ200×15 |
| 9 | Material of blades | 9CrSi | |
| 10 | Line speed | m/min | ≤40 |
Composed devices
1.Hydraulic coil car
----Convenient to carry the coils on the decoiler
2.De-coiler
----Supporting the coils and do the uncoiling
3.Hydraulic pinch and press device
----To do the pre-leveling and feed the plates into next process
4.Head cutting machine
----To cut the damaged heads or make the big coils into small coils
5.Slitting machine
---- Slit the wide plates into several narrow strips
6.Scrap winder
---- wind the leftover material on the both edge of the plates to ensure the safe working condition
7.Tension stand
-----To create the tension stress and do the pre-dividing to ensure the tight and even quality on the recoiler
8.Hydraulic Re-coiler
----Rewinding the finished strips
9.Hydraulic unload car
---- Carry out the finished coils
Working Flow of Cut-to-length Line
Decoiler---Leveling---Cutting---Recoiler
Machine pictures
