Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min
  • Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min
  • Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min
  • Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min

Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min

Place of Origin Wuxi, China
Brand Name Sussman
Certification CE, SGS, ISO
Model Number RF-ST
Product Details
Steel Thickness:
0.7-1.2mm
Forming Speed:
8-12m/min
Roller Material:
45# Steel
Main Shaft Diameter:
7.5Kw
Hydraulic Pressure:
12Mpa
Voltage:
380V/50HZ3Phase (as Customer's Request)
Warranty:
12 Months
Lifespan:
More Than 10 Years
High Light:

roofing sheet roll forming machine

,

metal roof roll forming machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiable
Packaging Details
Film and steel
Delivery Time
60 days after deposit
Supply Ability
10 sets/month
Product Description

0.7-1.2mm Color Steel Roof Panel Standing Seam Roll Forming Machine 8-12m/min





1. Technical Parameter



Number

Items

UnitType

RF-DL

1

Steel Thickness

mm

0.7-1.2mm

2

Forming Speed

m/min

8-12

3

Roller stands

stand

16 stands

4

Roller Material

mm

45# steel, coated with chrome



Shaft material and diameter

        mm

Ф76MM 45# steel, coated with chrome

5

Main Motor Power

Kw

7.5

6

Hydraulic cutting Power

Kw

4

7

Hydraulic pressure

Mpa

12

8

Power Supply



380V, 50HZ,3 phase

9

Tolerance

mm

1.5

10

Material of cutting



Cr12Mov HRC60-62

11 Machine weight T 6





2. Machine List

5 ton passive de-coiler

1 set

Guiding Platform

1 set

Main roll forming machine

1 set

Cutting machine

1 set

PLC Control box

1 unit

Hydraulic station

1 unit

Passive Out table

2 units

Safety cover

1 unit







3. Profile Drawing

Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min 0

Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min 1









4. Application



This machine is used to form the pre-painted sheet/GI material to be the standing seam for various roofing of the projects such as sports center, exhibition center, subway project, airport and stadium etc.







5. Packaging & Shipping



Before loading to the container, we will check the machine first

Second, make some protection on the machine, Such as, we will mpaint the coil on the roller and shaft, in case the roller and shast got corrosion and rusty during long time delivery



Third, we will make the plastic package on the easy damage parts, and fix all the parts into container by the steel wire rope, and ensure the machine will not damage when shaking on sea.

At last, we will take photos for customer when loading to container.



Color Steel Roof Panel Roll Forming Machine Standing Seam Forming Machine 8-12m / Min 2
