Stud And Track Roll Forming Machine
>
|
|
| Place of Origin | China |
| Brand Name | Sussman |
| Certification | SGS.CE.ISO |
| Model Number | SM-DC |
0.8-1.2mm Thickness Din Rail Channel Roll Forming Machine Punched Hat Channel Making Machine
Din rail roll forming machine is used to produce din rail which is the long metal strips that form the core part of a global industry standard component rail-mounting system in equipment cabinet racks. Din rails are designed for securely attaching electrical and industrial control products - such as circuit breakers, terminal blocks, power supplies, actuators, solenoids and so on - inside a typical equipment rack housing cabinet or frame.
Material for this machine is galvanized steel plate, snowflake plate and cold steel plate,we can according to customer design, manufacture different specifications of cold-formed.
The includes decoiler, Feeding and Leveling Device, main forming machine, hydraulic cutting device, the Frequency converter controls the motor speed, the PLC system controls length and quantity automatically. Our produced profile meet ISO, CE , UL standards, and our machine is applied to steel structure, industry or home.
Machine Technical Parameter
|
|
Items |
Specifications |
|
Material of coil |
Material Thickness |
0.8-1.2mm |
|
De-coiler |
Weight |
3 ton manual |
|
Forming system |
Rolling Speed |
0-10m/min |
|
Roller Stations |
About 12 stations forming |
|
|
Roller Material |
Gcr15 Steel with quenching |
|
|
Shaft Material |
45# Steel |
|
|
Main Motor Power |
7.5 kw |
|
|
Hydraulic cutting Power |
4 kw |
|
|
Cutting |
Material Of Cutting |
CR12 with quench treatment |
|
Hardness |
HRC58-62 |
|
|
Tolerance |
+-1.5mm |
|
|
Cutting blade |
1 set of cutting blade |
|
|
Electrical control system |
Electric Source |
380V, 50HZ, 3ph or as request |
|
Control System |
PLC with touch screen Japanese Panasonic and Yaskawa Brand |
|
|
|
Weight |
About 3.5 tons |
|
|
Way Of Drive |
1 inch single chain |
|
|
Size of machine |
Length 5500mm* Width 600mm* Height 800m |
Main Components
| Main Components | |
| 3 ton passive de-coiler | 1 set |
| Feeding with guide | 1 set |
| Main roll forming machine | 1 set |
| PLC control system | 1 unit |
| Hydraulic station | 1 unit |
| Stop cutting device | 1 unit |
| Safety cover | 1 unit |
| Out table | 2 units |
| Spare parts | 1 package |
Working Flow of Roll Forming Machine
feeding with guide—Roll forming——Cutting—Products collecting
