Trapezoidal Roof Panel Roll Forming Machine Peru TR4 TR5 TR6 Tile Making Machine
Roofing system roll forming machine has a big range of metal sheet profiles. It includes trapezoidal panel, PV-4, PV-6, 5V, corrugated panel, roof tile panel, step glazed tile, metal deck panel, standing seam panel, ridge cap, rain gutter, double layer/ two layer, K span panel and ridge cap machine. Its products are widely used in roof and wall system in workshop construction and housing construction.
Roof Zinc Machine can produce material thickness range 0.3-0.8mm or 0.12-0.4mm, material PPGI, galvalume steel and galvanized steel, also we can customized the machine according to your drawing. This machine design is unit one, which means the control box and motor are all put under the machine frame, when you get the machine, no need to assemble and connect the complicate cable of the machine, you only need to connect one main cable, then the machine is working. it saves more time and space.
Technical Data
Item NO |
Description |
Offered specification |
1.0 | Roll forming machine | |
1.1 | Rolling speed | 12-15m/min(not include cutting time) |
1.2 | Rolling thickness | 0.3mm-0.8m |
1.3 | Raw material | Color painted coils, Aluminium, Zinc, Galvanized |
1.4 | Main Motor | 7.5KW |
1.6 | Dimension | About 8000×1600×1200(mm) |
1.7 | Effective width | 1000mm |
1.8 | Feeding Coil width | 1219mm |
1.9 | Roller stations |
About 24 stations
|
1.10 | Roller material | 45#forge steel, coated with chrome |
1.11 | Shaft diameter | Φ76mm |
1.12 | Transmission | By chain 1.2 inch |
1.13 | Material of chain | 45# forged steel with frequency quenching, 12A |
1.14 | Material of cutting | Cr12Mov with quench HRC58-62° |
1.15 | Tolerance | 10m+-1.5mm |
1.16 | Hydraulic station | 4kw |
