Roofing Flashing Aluminum 2-1/2" Face And 3" Face Drip Edge Roll Forming Machine

Place of Origin	Wuxi, China
Brand Name	Sussman
Certification	CE, SGS, ISO
Model Number	RF-ST

Product Details

Steel Thickness:

0.3-0.8mm （28 Gauge, Galvanized Steel Most）

Roller Stations:

16roller Stations

Main Shaft Diameter:

7.5Kw

Raw Material:

Galvanized Steel, Aluminum

Roller Shaft:

76mm 45# Steel Solid,Precision

Shaft Material:

45# Steel Solid,Precision

Highlight:

PBR roof panel roll forming machine

22 stations roof sheet making machine

single chain drive roof panel machine

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

negotiable

Packaging Details

Film and steel

Delivery Time

60 days after deposit

Supply Ability

10 sets/month

Product Description

Roofing Flashing Aluminum 2-1/2" Face And 3" Face Drip Edge Roll Forming Machine

1. Roofing machine technical parameter

Coil Material	Material	PPGI Color steel, galvanized steel
Coil Material	Material thickness	0.3-0.8mm
ROLL MACHINE	Frame Structure	350H frame
	Roller Station	About 20-22 roller stations
	Roller Shaft	76mm 45# Steel Solid,Precision
	Shaft Material	45# Steel Solid,Precision
	Roller Info.	45# steel harden chromed plated
	Transmission	Chain 1 inch
	Motor Power	7.5KW
	Output Speed	About 12-15m/min
CUTTING	Cutting Type	Hydraulic Automatic
CUTTING	Cutting Blade	Cr12Mov,hardness 60-62℃
HYDRAULIC SYSTEM	Installation	inside,easy for operation
HYDRAULIC SYSTEM	Pump Motor	4KW
COMPUTER SYSTEM	Electrical Control	PLC Siemens
	Length Control	Encoder Omron
	Length Tolerance	±1.5mm
	Touch Screen	Siemens

2. Roofing Machine List

5 Tons passive de-coiler	1 set
Plastic film device	1 set
Manual pre-cutting oe electric	1 set
Main roll forming machine	1 set
Hydraulic cutting machine	1 set
PLC Control box	1 unit
Hydraulic station	1 unit
Passive Out table	2 units
Safety cover	1 unit

3. Profile Drawing of drip edge

This D-style metal drip edge is a 90° metal edge flashing with an extended leading edge that supports overhanging shingles and helps keep water away from the fascia.

This product is available in galvanized, or pre-painted black, brown, white, or gray.

Roofing Flashing Aluminum 2-1/2" Face And 3" Face Drip Edge Roll Forming Machine 0

5. Applications

Roofs, flashing and industrial buildings, warehouses and constructions in general.

Roofing Flashing Aluminum 2-1/2" Face And 3" Face Drip Edge Roll Forming Machine 1

5. Roofing drip edge Machine Photo

Roofing Flashing Aluminum 2-1/2" Face And 3" Face Drip Edge Roll Forming Machine 2
