Type 65-400 Beam Standing Roofing Sheet Roll Forming Machine Thickness 0.7-1.2mm

Large Image : Type 65-400 Beam Standing Roofing Sheet Roll Forming Machine Thickness 0.7-1.2mm

Product Details:

Place of Origin:	Wuxi, China
Brand Name:	Sussman
Certification:	CE, SGS, ISO
Model Number:	RF-BS

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	Film and steel
Delivery Time:	50 days after deposit

Contact Now

Chat Now

Detailed Product Description

Material:	0.7-1.2mm For Color Coated Steel	Forming Speed:	12-16
Roller Stations:	15 Stations	Way Of Drive:	1.2 Inch Single Chain
Roller Material:	#45 Steel Heat Treatment	Shaft Material:	#45 Steel Heat Treatment
Shaft Diameter:	70mm	Cutting Way:	Hydraulic Cutting
High Light:	roofing sheet roll forming machine , metal roof roll forming machine

Type 65-400 Beam Standing Roofing Sheet Roll Forming Machine Thickness 0.7-1.2mm

Technical Parameter

1. material thickness: 0.7-1.2mm for color coated steel

2. forming speed: 12-16m/min

3. roller stations: 15 stations

4. roller material: 45# steel , coated with chrome, heat treatment, HRC58-62

5. shaft diameter: 70mm

6. main motor power: 5.5Kw

7. hydraulic cutting power: 3Kw

8. cutting blade material: Cr12

Machine Components

5 ton passive de-coiler	1 set
Main roll forming machine with wheels	1 set
PLC Control box	1 unit
Hydraulic station	1 unit
Out table	2 units
Curving machine	1 unit
Seaming machine	1 unit

Machine Photo

Type 65-400 Beam Standing Roofing Sheet Roll Forming Machine Thickness 0.7-1.2mm 0

Type 65-400 Beam Standing Roofing Sheet Roll Forming Machine Thickness 0.7-1.2mm 1

Samples
