0.7-1.2mm Garage mental Shutter Door Roll Forming Machine , Metal Forming Equipment PLC Control

Sussman Machinery can design a variety of roller shutter machines to produce roller shutter slats, from simple safety roller shutters to those designed for weatherproofing, custom designed roller shutters, and even fire shutters, fire shutters, very fast rolling Roller shutters on curtains or sectional door shutters, etc. We can also add servo motor and non-stop tracking cutting on the roller blind making machine, the speed can be 25-30m/min. All data are set in the PLC computer program (Delta or Mitsubishi optional)

Working flow

decoiler—→level device—→main roll forming machine—→hydraulic cutting—→ run out table

Profile drawing

Parts of machine

The technique data

Materials to form shutter door : 0.7-1.2mm, Galvanized coils

Forming steps: about 12 steps

Material of rollers: GCr15 steel, precision-machined, high frequency quenching HRC58-62, diameter of rollers: ＞￠150

Material of main shaft : 45# high quality steel (diameter＞￠50)

Chains’ material: 45# steel, high frequency quenching, circular pitch:38.1; number of teeth: 13

Cutting : hydraulic cutting; quenching HRC58-62

Electronic control: Plc control Panasonic Japanese brand

Dimension of machine: 4500mmX500mmX800mm

Drive system: chain drive, 7.5KW main motor power, working speed:12-15m/min;
