2" 3" Australian Metal Sectional Garage Door Guide Rail Curve Bending Machine
Technical Data:
| Items | Specifications | |
| Material of coil | Material Thickness | 1.5-2.0 mm galvanized steel |
| Radius | Max curved degree | 360 degree |
| Max curved radius | 450mm | |
| Hydraulic station | Y132S | 3 kw |
| Pressure | 14mpa | |
| Valve | BSG-01 | DC24 TAFEN |
| 03-3C2 | TAFEN | |
| Bearing | Haerbin | |
| Curved system | Curve Speed | 10-50 degree/s |
| Machine size | Length | 4800mm |
| Width | 900mm | |
| Height | 1160mm | |
| Machine weight | kg | 2500kgs |
| Electrical control system | Electric Source |
220V, 60HZ,3 phase Also can satisfy Customer’s require |
Profile Drawing:
Machine Shows:
Application:
1) Easy in installation and maintenance.
2) Hardened structural steel and components provide long life and safe operational stability.
3) Adopting advanced world famous brand components in controlling parts, electric parts and operation parts.
4) Running in an automation, high durability and stability.
5) Compact design, meet custom demands.
