380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color

380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color
380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color 380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color 380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color 380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color

Large Image :  380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color

Product Details:
Place of Origin: China
Brand Name: Sussman
Certification: CE ISO
Model Number: RF-SD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiable
Packaging Details: film
Delivery Time: 45-60days
Payment Terms: L/C, T/T
Supply Ability: 10 sets per month

380V 15 M / Min Shutter Door Forming Machine CE Standard Customized Color

Description
Voltage: 380V Raw Material: Galvanized Steel
Tile Type: Steel Color: As Customer Requirement
Control System: Fully Automatic Speed: 15/min
High Light:

cold roll forming machine

,

sheet metal roll former

 380V 0.4~1.2mm Thickness 15m/min Shutter Door Roll Forming Machine CE Standard





Process Flow of Shutter door roll forming machine :



Uncoiling→ (Perforation machine )→Feeding material into machine→Roll forming→Measuring length→ (punching part)→Auto cutting→Products receiving

N.B: you can choose the Perforation machine and punching part as your demand.



As a manufacturers,we can make the High Quality Roller Shutter Slat Roll Forming Machine Price by customer`s demand, with a profile drawing and thickness, we can do design the machine quickly.Until now,we can do many kinds of shutter door machine,such as shutter door machine with perforation and holes,Australian-style shutter door and shutter door slat. And now, we start the new business about shutter door machine.Here is some profile drawings for you reference.

Shutter door roll forming machine

Parameters of Shutter door roll forming machine

Raw material



Type: colored steel plate, galvanized plate, or aluminium plate



Thickness: 0.5---1.5 mm (As customer`s need)



Material hardness: 550 Mpa---350 Mpa



Material width: 117mm-310mm (According to customer`s profile)



Decoiler



Max width: 300mm (According to customer`s profile)



Inner diameter: 450-650mm (According to customer`s profile)



Max Loading capacity: 5 T



Shutter door roll forming machine



Perforation machine



Power: 4KW (According to the thickness)

The distribution,area and size of the holes: As customer`s need (The basic information for quote the Perforation machine)

Thickness: 0.3---1.5 mm (As customer`s need)



Shutter door roll forming machine



Main roll machine of Shutter door roll forming machine



Working efficiency: 0-30m/min



Forming by rolling: Roll 12 rows (Final rollers depend on the design)



Roller material: Gcr12MoV quenched



Shaft material: 45#steel processing



Diameter of shaft: 50mm (Final rollers depend on the design)



Main part power: 5.5kw (Depend on the thickness of material and size of machine)



Hydraulic motor power: 3kw (Depend on the thickness)



Scissor material: Gcr12MoV quenched



Roller material: Gcr15MoV



Voltage: 380V, 50HZ,3 phase (As customer`s need)



Transmission: Gear box (Chain and gear box depend on thickness and customer`s need)



Shutter door roll forming machine



FAQ



1. Do you have after sales support?

Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.



2. What can you do if the machine broken?

Our machine's warranty period is 12 months,if the broken parts can't repair,we can send the new parts to replace the broken parts freely,but you need pay the express cost yourself.if after warranty period,we can through negotiation for to solve the problems,and we supply the technical support for the whole life of the equipment.



3. Can you be responsible for transport?

Yes,please tell me the destination port or address.we have rich experience in transport.
